Features and Fuctions:
Light source: 700W LED, Life: ≥2000 hours
Color temperature: 8000K
Light output aperture: 138mm, Zoom range: 4-36°
Illumination: 13000Lux@15 m 4 degrees
Display: standard mode Ra≥75, high display mode Ra≥90
Horizontal scanning: 540° , using advanced magnetoelectric positioning system,
16bit scanning
Vertical scanning: 270°, using advanced magnetoelectric positioning system, 16bit
scanning
Color system: 1 color wheel, 7 colors + white. Color mixing system: CMY infinite
color mixing
CTO color temperature: 3200-8000K adjustable
Fixed gobo: 1 fixed gobo plate, 4 kinds of metal gobo + dynamic flame
Rotating gobo: 1 rotating gobo plate, 7 kinds of pluggable glass gobos
Cutting system: 4-piece graphic cutting system, accurate positioning, 90°rotatable
Prism: one 3 prism, reversible rotation, adjustable rotation speed
Focus: Electric focus
Atomization: 1 independent soft light mirror +1 display finger
Strobe: 0~20Hz, optional random stroboscopic and pulse stroboscopic
Dimming: 0~100% linear dimming
Control mode: DMX512, self-walking, voice control, RDM
Channel: 38/41CH
Display: Touch control interface, display temperature, lamp brightness
Input voltage: AC90-240V, 50/60 Hz
Power connection: Seetronic power socket /16A waterproof plug is optional
Signal connection: Seetronic signal socket/three-core signal waterproof plug
Power: 850W, Power factor: 0.85
Working environment: -20℃ ~ 45℃, Protection level: IP66
Size: 41.5*24*76.6cm, Net weight: 28kg
Outer shell: magnesium alloy shell, black outdoor paint
Heat dissipation system: ultra-quiet air cooling + magnesium alloy body + copper
tube heat sink
