SPECIFICATIONS AND FEATURES:
• DMX-2-6 and DMX-1-12 two working modes can switch
• 2x DMX IN and 12x OUT separate optical isolation
• Black aluminum profile panel
• M12 hole for clamp and safety cables to install on truss
• Power input:90-250V AC，47-63Hz
•Work temp: -30—70
•Fuse: T1A,250Vac
•Power: 10W
•Weight: 1.95KG
•Size: 482.6x44.5x143mm
•Standard: IEC/EN/UL62368
规格和参数:
•DMX-2-6和DMX-1-12工作模式快速切换
•2路输入和12路输出光电隔离
•黑色喷砂氧化铝型材面板
•支持用M12灯钩固定在桁架上以及保险绳安装
•支持标准 1U 机柜安装
•工作电压：100-240Vac，50/60Hz
•功率：10Wmax.
•保险管参数：T1A,250Vac
•电源座：PowerCon IN/OUT
•尺寸：482.6*44.5*143mm（W*H*D）
•净重：1.9Kg
