SPECIFICATION

LIGHT SOURCE

Main Light: 5 x 120W RGBL 4in1 LEDs

Outer Circle: 120 x 0.5W RGB LEDs

Total Lumen Output of Fixture: 13,000 lumens

Life Expectancy: 20,000 hours

OPTICAL SYSTEM

Beam Angles: 3°-30°

Field Angles: 4°-35°

CONTROL AND PROGRAM

4 button touch control panel

Display: LCD display

Protocols: DMX512, RDM

DMX Protocol Modes: 2

Control Channels: 41/71CH

Firmware Upgrade: Upgrade via DMX link

PAN & TILT

Pan Movement: 59°

Tilt Movement: 221°

Automatic Pan/Tilt position correction

Resolution: 16 bit

OTHER EFFECTS

Outstanding strobe effects with variable speed

Variable light adjustment from 0-100% dimming

Outstanding color mixing effects

Outstanding color macro effects

Linear focusing structure

ELECTRICAL AND CONNECTORS

Input Voltage Range: 100-240V~ 50/60Hz

Power Consumption: 935W

Power In/Out: Waterproof power connector in/out (True1 type)

Data In/Out: 3-pin XLR

FIXTURE SPECIFICATION

Fixture Size:1002*196*334mm

Net Weight: 26.6kg

Protection Rating: IP33

Installation

Horizontal or vertical mounting

Universal working position

2 x omega brackets

Safety cable attachment point
